5.2 Setting the wheel size display to remind you of your bicycle inspection. Press the RIGHT key to switch off
After inserting new batteries (7.1), new start or change the wheel size. this notice. After setting the inspection interval, the display will switch to the mode
for setting the time.
5.5 Setting the 12/24-hour display
Press and hold the LEFT key and the 24-hour display blinks. With the RIGHT key,
choose between the 12-hour and 24-hour display of the CLOCK and confirm
C = Distance in millimetres per rotation with the LEFT key.
5.6 Setting the clock
Determining the wheel size; mark the front wheel and the ground at the same Immediately after choosing the 12/24-hour display you will be able to set the
point, or use the valve as orientation. Move the wheel one wheel revolution time. The hours display flashes. Press the RIGHT key: The hours display is increased
forwards and measure the covered distance in mm. This is your entry value. by one. Press the LEFT key: The minutes display blinks. Press the RIGHT key: The
Basic setting display: 2124 (=mm), The ones digit 4 blinks. Press the RIGHT key: minutes display is increased by one. Press the LEFT key to confirm the time entry.
The ones digit is increased by one. The settings are now completed and the bicycle computer is ready for use.
For all settings: Keep the RIGHT key pressed down – the respective numbers will 5.7 Bicycle computer check
progress faster. Confirm your selection by pressing the LEFT key. The tens digit To check if the bicycle computer and sensor were installed correctly, press the
now blinks. Press the RIGHT key: The tens digit is increased by one. Please set the LEFT key to activate the display. Place the computer in the computer mount and
following digits in the same manner. The thousands digit can only be set from 0 turn the front wheel of your bicycle and the speed will be indicated.
to 5. Finally, press the LEFT key once more to confirm the setting. 5.8 New start/Reset
5.3 Selecting KM/H Miles To reset entered and stored data, press both the LEFT and RIGHT keys at the
The choice of the unit of measurement comes directly after entering the wheel same time for approx. 3 seconds. All settings will have to be re-entered after the
size. Press the RIGHT key to choose between KILOMETRE (KM) and MILES (M) new start/reset. (see Point 5.2 Setting the wheel size – 5.6 Setting the clock).
and confirm with the LEFT key. The system then switches to the mode to set the 5.9 Automatic start/stop
inspection interval.
Each time before the bicycle computer is used (display is blank), it must be
5.4 Setting the inspection interval switched on by pressing a key. When you start off, all measurements begin auto-
The display 600 KM flashes. This function permits you to set the kilometres up matically until the bicycle stops. When you continue your ride, the measurements
to the next bicycle inspection. Pressing the RIGHT key lets you make settings of continue. The bicycle computer switches off automatically to save the battery
200/400/600 or 800 kilometres. Use the LEFT key to confirm the set value. After after the bicycle has stopped moving for more than 5 minutes.
the kilometres you set have been reached, a spanner symbol will appear in the
BAFahrradPC0511_DE-FR-GB-IT-NL-HU-RO-PL.indb 1
6. Modes/Functions • Time
Speed tendency and comparison is always displayed during the trip.
After starting up the bicycle computer, the display will show the speed and • Speed tendency
the time. Display of current speed: The wheels of the bicycle symbol rotate faster
Speed Is continuously calculated and updated and is ALWAYS displayed at the or slower.
top right. Measuring range: 0.1 – 99.9 • Speed comparison
Press the RIGHT key to switch between the following modes: On the right next to the speed display you will see "+" or "-".
• ODO (total distance travelled) This indicates that you are riding faster or slower than the previously travelled
All travelled kilometres (miles) will be stored. Maximum memory range: average speed. (AVS)
• DST (trip distance) • Instantaneous memory
Automatic start when bicycle trip begins. Maximum measuring range 999.9 The bicycle computer has a unique instantaneous memory that can record
• MXS (maximum speed) the values for trip distance (DST), average speed (AVS) and trip time (TM)
The maximum achieved speed is stored. Maximum measuring range: 99.9 at the end of the driven distance. Press the LEFT key at the end of a stage.
• AVS (average speed) The values for DST, AVS and TM are stored and can be reviewed at a later
Maximum measuring range: 99.9 period. You can view the saved values by repeatedly pressing the RIGHT key.
• TM (trip time/trip chronometer) To exit this mode, press the LEFT key. The instantaneous memory is suitable
Automatic start when bicycle trip begins. Maximum measuring range: for, e.g. capturing data after a race to quickly save the values after crossing
9 hrs 59 min 59 sec the finish line.
• Temperature 6.1 Resetting the route data (DST, TM, AVS) to zero
Press and hold the LEFT key in the temperature mode: C (Celsius) blinks, Press the RIGHT key to display (DST) and keep the LEFT key pressed for approx. 3
use the RIGHT key to now switch to F (Fahrenheit). seconds. The three route data (trip distance counter – DST, trip time – TM, average
Confirm the desired setting with the LEFT key. speed – AVS) will be reset to zero.
• SCAN (scan function)
6.2 Resetting the maximum speed (MXS) to zero
Rolling display of functions: Continue pressing the RIGHT key until you reach Press the RIGHT key repeatedly until the maximum speed (MXS) is displayed
the SCAN mode. SCAN appears in the display. In this mode, the functions and hold down the LEFT key for 3 seconds. The maximum speed (MXS) is
(DST, MXS, AVS, TM) will be displayed automatically at 4-second intervals reset to zero.
in succession. 6.3 Manual entry of total kilometres
• One-time scanning quick run-through To enter the total kilometres (ODO) after battery replacement or new start/reset, all
If you keep the RIGHT key pressed for approx. 2 seconds, a one-time scanning of the settings from Point 5.2 Setting the wheel size to Point 5.6 Setting the clock
quick run-through occurs. must be entered again.
Then press the RIGHT key until you reach the mode (ODO). Now keep the LEFT key 8. declaration oF conForMity
pressed down for approx. 3 seconds, the last digit of the total kilometres begins
to blink. Press the RIGHT key to set the number and confirm the entry by pressing We confirm that the bicycle computer conforms to the fundamental requirements
the LEFT key. Then select the next digit for the entry. Repeat the procedure until the of the following European directives: the accordance of this product with the
desired value for the total kilometre counter has been set. Press the LEFT key again directives is verified by the full compliance with the harmonised and non-
to return to the normal (ODO) mode. harmonised standards listed:
2004/108/Ec EMc Directive
7. Battery replaceMent EN 61000-6-3:2001 (2007+A1:2011)
EN 61000-6-1 (2007)
7.1 Bicycle computer
Use a coin to unscrew the battery compartment lid at the back of the bicycle 9. description oF Fault
computer. Insert the 3 V battery so that the positive pole (+) is visible. Replace the lid
and screw shut. After the batteries have been inserted, all settings must be re-entered If a fault occurs, first check the following points before submitting the bicycle
(see Point 5.2 Setting the wheel size). computer for complaint.
No speed indication:
• Check for correct magnet/sensor alignment.
• Check the batteries.
• If the battery is too weak, there will be no display.
F
Incorrect speed measurement or speed display at standstill, or high incorrect
maximum speed display
• Check if the wheel size was set correctly.
• Check if the correct KM/Miles setting is selected.
• Check if the magnet and sensor are positioned correctly.
• RF (radio frequency) interference from a chest strap. Do not get too close to
the bicycle computer with a chest strap, as the speed indicator will begin to
"run".
• Unknown atmospheric or RF disturbances, atmospheric or radio interference,
high-voltage lines, railroad lines, etc. can also cause an incorrect speed
display.
Display is black Bicycle coMputer
Too high temperature, or display is exposed to direct sunlight, will return to
normal after cooling off.
Display shows erratic numbers:
Remove the bicycle computer battery and reinsert.
Article no. 0511
No display
• Check the battery
• Is the battery inserted correctly? Observe +/-.
10. Warranty provisions
SI-Zweirad bicycle computer Art. No.: 0511
This bicycle computer has a 2-year warranty. Warranty begins as of the purchase
date (receipt, proof of purchase). During the warranty period, complaints about
defective bicycle computers can be made with your distributor, or at the service
address specified below. During this period we will correct free of charge all
defects that can be attributed to material defects or malfunctions. Excluded from
the warranty are batteries, improper handling, falls, impacts and the like. A new
warranty period does not begin after repairs or replacement of the device. The
warranty period of 2 years as of date of purchase remains definitive.
Please send your carefully packaged bicycle computer with your receipt to the
following address:
Prophete GmbH u. Co. KG
Lindenstrasse 50
33378 Rheda-Wiedenbrück
15 functions
Phone: +49 (0) 5242 4108-59
Fax: +49 (0) 5242 4108-73
Email address: service@prophete.net
oPEratinG instructions
Website: www.prophete.de
