C) Depth Detection Specifications; Cleaning - TOOLCRAFT OG08 Bedienungsanleitung

The sensor detects 50 or 60 Hz AC voltages of 110 V/AC, 240 V/AC and 380 V/AC. Wires/materials that do
not carry a voltage are only detected in metal mode.
Objects carrying an AC voltage are detected both in metal and wood modes. Move the multidetector back
and forth to determine the exact position of the object. A flashing red LED (7) and a rapid beep indicate that
the AC voltage conductor is within range of the sensor (9).
For best results, there should be a current flowing through the conductor. To improve the detection
accuracy, turn on the appliances that are connected to the AC voltage conductor.

c) Depth detection specifications

Material
Copper/steel
AC voltage cable
Wood

10. Cleaning

Never use aggressive detergents, rubbing alcohol or other chemical solutions, as these could damage the
housing or even impair the functioning of the product.
• Before cleaning the product, always disconnect it from the power supply by removing the battery.
• Use a dry, lint-free cloth to clean the product.
Dimensions
Ø 20
Ø 16
Ø12
Ø 6
Depth
8 cm / 6 cm
7 cm / 6 cm
6 cm / 5 cm
5 cm / 5 cm
5 cm
2 cm
Accuracy
±1 cm
23
