7. Operating elements

Multidetector
7
6
5
4
3
2
1
1 Metal/AC voltage detection button
2 Wood detection button
3 On/off button
4 LCD display
5 Green LED
6 Yellow LED
LCD display
C
B
A
D E F
7 Red LED
8 Felt pad (top)
9 Sensor
10 Data label
11 Felt pad (bottom)
12 Battery compartment cover
A Location indicator
G
B Depth indicator (metal)
C Battery level indicator
D Wood mode (growth rings)
E AC voltage mode (flash)
F Metal mode (double T)
H
G Non-magnetic metals mode
H Signal strength indicator
8
9
10
11
12
