EN
Overview
This is the TruVision IR Dome Camera Pocket
Guide for models TVD-TIR6-SR(-P), TVD-TIR6-
MR(-P) and TVD-TIR6-HR(-P). This pocket guide
describes a standard installation.
The camera consists of the following:
 Camera with power and video output cables
 Camera shroud
 Mounting bracket
Mounting hardware

Hex wrench

 Gang box adapter plate (for TVD-TIR6-MR(-P)
and TVD-TIR6-HR(-P) models only).
 Rubber plug 4 pieces (for TVD-TIR6-MR(-P) and
TVD-TIR6-HR(-P) models only)
Refer to the figures on pages 3, 5 and 7 when
performing the camera setup procedures.
