6. Press the ◄ ► key to confirm the
temperature of the tested battery.
7. Test the battery for few seconds.
8. When the test is completed, the display shows the results
as following. {Press the◄ ► key to select: SOH (STATE OF
HEALTH) or SOC (STATE OF CHARGE)}.
GOOD & PASS
The battery is good & capable of
holding a charge.
GOOD & RECHARGE
The battery is good but needs to
be recharged.
RECHARGE & RETEST
Battery is discharged, the
battery condition cannot be
determined until it is fully
charged. Recharge & retest the battery.
BAD & REPLACE
The battery will not hold a charge.
It should be replaced immediately.
BAD CELL & REPLACE
The battery has at least one cell
short circuit. It should be replaced
immediately.
9. End of test. Precede the printout if needed.
GOOD & RECHARGE
RECHARGE & RETEST
BAD CELL & REPLACE
- GB.9-V1 -
ABOVE 32°F/0°C?
YES/NO
TESTING
GOOD & PASS
××.××V ×××× SAE
××.××V ×××× SAE
××.××V ×××× SAE
BAD & REPLACE
××.××V ×××× SAE
××.××V ×××× SAE
