CONNECTIONS • ANHANG
B
A
GREY SPEAKERS FRONT DX
VIOLET SPEAKERS REAR DX
YELLOW MEMORY BACK-UP
BLUE REMOTE
AUDIO OUTPUT
IR OUTER STEERING
WHEEL
AERIAL
1 3 5 7
2 4 6 8
5 7
4 8
WHITE SPEAKERS FRONT SX
GREEN SPEAKERS REAR SX
BLACK GROUND
RED IGNITION SWITCH
7
FR/D
RED DX
WHITE SX
