AC Voltage
RANGE
50Hz -- 500Hz
400.0mV*
4.000V,
40.00V, 400.0V
1000V
CMRR :
Input Impedance : 10MΩ, 30pF nominal (1000MΩ for 400.0mV range)
*Selection by RANGE button manually, and is specified from AC 10mV (AC 40mV
for True RMS model BM807) and up
DC Current
RANGE Accuracy
2.0% + 5d
400.0μA
1.2% + 3d
4000μA
40.00mA 2.0% + 5d 3.3mV/mA
400.0mA 1.2% + 3d 3.3mV/mA
4.000A 2.0% + 5d 0.03V/A
10.00A* 1.2% + 3d 0.03V/A
*10A continuous, 20A for 30 second max with 5 minutes cool down interval
AC Current
RANGE Accuracy
50Hz -- 500Hz
2.0% + 6d
400.0μA
1.5% + 4d
4000μA
40.00mA 2.0% + 6d
400.0mA 1.7% + 4d
4.000A 2.0% + 6d
10.00A* 1.8% + 4d
*10A continuous, 20A for 30 second max with 5 minutes cool down interval
Diode Tester
Open Circuit Voltage
< 1.6 VDC
Type-K Temperature (BM806 & BM807)
RANGE
-20 OC TO 300 OC
-4 OF TO 572 OF
*Type-K thermocouple range & accuracy not included
Elma 805/807
Accuracy 1)
4.0% + 5d
1.5% + 5d
4.0% + 5d
>60dB @ DC to 60Hz, Rs=1kΩ
Burden Voltage
0.15mV/μA
0.15mV/μA
1)
Burden Voltage
0.15mV/μA
0.15mV/μA
3.3mV/mA
3.3mV/mA
0.03V/A
0.03V/A
Test Current (Typical)
0.25mA
Accuracy*
2% + 3 OC
2% + 6 OF
