SPECIFICATIONS

INPUTS:
OUTPUTS:
SIGNAL-TO-NOISE RATIO:
(max output
JIS-A weighted)
DISTORTION:
FREQUENCY RESPONSE:
CHANNEL EQUALIZER:
CHANNEL FADER KILL:
CROSSFADER KILL:
CROSSTALK:
Line:
Mic:
Phono:
Line:
Headphone:
Line:
Mic:
Phono:
Line:
Mic:
Phono:
Bass:
Middle:
Treble:
MANUAL VERSION 1.0
21
10k input impedance
80mV RMS sensitivity for 0dB output
600 input impedance, unbalanced
1.5mV RMS sensitivity for 0dB output
400mV RMS max input
47k input impedance
1.3mV RMS sensitivity @ 1kHz for 0dB output
7V RMS max
0.5W into 47
> 100dB
> 95dB
> 85dB
< 0.05%
20Hz – 20kHz ±0.5dB
20-15kHz ±0.5dB
±1dB (except for controlled attenuation of -3dB
@20Hz to reduce rumble and feedback)
+12/-35dB @ 20Hz
+12/-25dB @ 1.3kHz
+12/-20dB @ 15kHz
> 90dB @ 1kHz
> 75dB
> 80dB @ 1kHz
