TECHNICAL SPECIFICATION
Model number: LDEB82G3
Product type: PA loudspeaker
Type: Passive
Low/mid driver 8"
dimensions:
Low/mid driver 203.2 mm
dimensions (mm):
Woofer magnet: Ferrite
Woofer brand: Custom-made
Woofer voice coil: 2"
Woofer voice coil 50.8 mm
(mm):
Horn: BEM optimzed CD
horn
HF driver dimensions: 1"
HF driver dimensions 25.4 mm
(mm):
HF driver magnet: Ferrite
HF driver brand: BMS
HF driver voice coil: 1"
HF driver voice coil 25.4 mm
(mm):
Dispersion (H x V): 90 x 50°
Load rating (RMS): 250 W
Peak power: 500 W
Frequency response: 70 - 20,000 Hz
SPL (1W/1m): 95 dB
Max. SPL: 119 dB
Impedance: 8 Ohm
Protection circuits: HF Driver
Loudspeaker inputs: 1
Speaker input Speakon com-
connections: patible
Loudspeaker outputs: 1
Speaker output Speakon com-
connections: patible
Cabinet material: 12 mm Plywood
Cabinet surface: Polyurea
Cabinet construction: Vented
monitor angle n.a.
Width: 270 mm
Height: 457 mm
Depth: 290 mm
LDEB102G3 LDEB122G3
PA loudspeaker PA loudspeaker
Passive Passive
10" 12"
254 mm 304.8 mm
Ferrite Ferrite
Custom-made Custom-made
2" 2.5"
50.8 mm 63.5 mm
BEM optimzed CD BEM optimzed CD
horn horn
1" 1"
25.4 mm 25.4 mm
Ferrite Ferrite
BMS BMS
1" 1"
25.4 mm 25.4 mm
90 x 50° 90 x 50°
300 W 400 W
600 W 800 W
65 - 20,000 Hz 58 - 20,000 Hz
96 dB 99 dB
121 dB 125 dB
8 Ohm 8 Ohm
HF Driver HF Driver
1 1
Speakon com- Speakon com-
patible patible
1 1
Speakon com- Speakon com-
patible patible
12 mm Plywood 15 mm Plywood
Polyurea Polyurea
Vented Vented
54° 54°
325 mm 390 mm
527 mm 627 mm
308 mm 377 mm
LDEB152G3 LDEB282G3
PA loudspeaker PA loudspeaker
Passive passive
15" 2 x 8"
381 mm 2 x 203.2mm
Ferrite Ferrite
Custom-made Custom-made
3" 2"
76.2 mm 50.8mm
BEM optimzed CD BEM optimzed CD
horn horn
1" 1"
25.4 mm 25.4mm
Ferrite Ferrite
BMS BMS
1" 1"
25.4 mm 25.4mm
90 x 50° 90 x 50°
500 W 400W
1000 W 800W
50 - 20,000 Hz 58 - 20000Hz
100 dB 97dB
127 dB 123dB
8 Ohm 8Ohm
HF Driver HF Driver
1 1
Speakon com- Speakon com-
patible patible
1 1
Speakon com- Speakon com-
patible patible
15 mm Plywood 12 mm Plywood
Polyurea Polyurea
Vented Vented
54° n.a.
480 mm 270mm
737 mm 756mm
455 mm 290mm
