CABLE TESTER CT100 Bedienungsanleitung
6. Kabeltypen
Balanced ¼" TRS connector
For connection of balanced and unbalanced plugs,
ring and sleeve have to be bridged at the stereo plug.
6,3 mm, 3,5 mm & TT-Stecker (Pin 3 muss nicht zwingend belegt sein)
Unused
Pin 3
Pin 1
(ground)
MIDI-Stecker (2 Pins sind nicht belegt)
strain relief clamp
sleeve
ring
tip
sleeve
ground/shield
ring
cold (-ve)
tip
hot (+ve)
Unused
Pin 2
