List of parts

Reference No.
1
2
3
4
5
6
7
8
9
10
11
12
Number Description
1 Base arm
1 Ball bearing 6901Z
1 Drive belt 600 x 7/5
1 Toothed idler wheel M14
1 Ball bearing 6903Z
1 Lid arm
1 Lower fl ange ø45 x M14 (22,2/25,4)
1 Nut fl ange ø45 x M14 (25,4)
1 Toothed drive wheel M14
2 Peg ø5 x 16
1 Head screw M5 x 25
3 Head screw M5 x 16
UK
Part No.
SMFE/A1
SMF/A1007
SMFE/R
SMFE/A1016
SMF/A1008
SMFE/A2
SMFE/A1009
SMFE/A1010
SMF/A1011
SMFE/A1001
SMFE/A1002
SMFE/A1004
