Working with the application for Mac OS users
Installing software
Browse to the mac folder on the installation CD and copy MicroCapture file
to the desktop.
Operating the microscope
Use a USB cable to connect the microscope to your computer. Run the MicroCapture
application by double-clicking its icon.
Observing specimens
A magnified image of the observed specimen may be seen in the main window of the
application.
Image resolution
From the Options menu, select Preview Size to set the image resolution. Keep in mind
that the preview window cannot be resized (standard resolution is 640x480). The image
resolution is shown in the bottom left corner of the preview window.
Date and time
From the Options menu, select Date/Time to display or hide the date and time
of capture during preview.
Capturing an image
Click the corresponding icon on the toolbar or select Photo from the Capture menu
to capture an image. An image thumbnail will appear on the right side of the main
window.
Recording a video
Click the corresponding icon on the toolbar or select Video from the Capture menu
to start recording a video.
Note: during recording, the camcorder icon on the toolbar will turn red. Click the icon
again to stop recording.
Editing images and videos
Image and video thumbnails are displayed on the right side of the main window of the
application. Double-click an image thumbnail to open it in a separate preview window.
Editing images with MicroCapture application is similar to working with other
applications in Mac OS.
4

Care and maintenance

Never, under any circumstances, look directly at the Sun, another bright source of light or
at a laser through this device, as this may cause PERMANENT RETINAL DAMAGE and may
lead to BLINDNESS. White LEDs are very bright; do not look at them as this may cause
permanent damage to your vision. Take necessary precautions when using the device with
children or others who have not read or who do not fully understand these instructions.
After unpacking your microscope and before using it for the first time check for integrity
and durability of every component and connection. Do not try to disassemble the device on
your own for any reason. For repairs and cleaning of any kind, please contact your local
specialized service center. Protect the device from sudden impact and excessive
mechanical force. Do not apply excessive pressure when adjusting focus. Do not
overtighten the locking screws. Do not touch the optical surfaces with your fingers. To
clean the device exterior, use only special cleaning wipes and special optics cleaning tools
from Levenhuk. Abrasive particles, such as sand, should not be wiped off lenses, but
instead blown off or brushed away with a soft brush. Do not use the device for lengthy
periods of time, or leave it unattended in direct sunlight. Keep the device away from water
and high humidity. Be careful during your observations, always replace the dust cover after
you are finished with observations to protect the device from dust and stains. If you are not
using your microscope for extended periods of time, store the objective lenses and
eyepieces separately from the microscope. Store the device in a dry, cool place away from
hazardous acids and other chemicals, away from heaters, open fire and other sources of
high temperatures. To avoid data loss or equipment damage, always close the application
first, and then disconnect the microscope from your PC. Wait until the illumination goes off
completely, and disconnect the microscope. Seek medical advice immediately if a small
part or a battery is swallowed.

Battery safety instructions

Always purchase the correct size and grade of battery most suitable for the intended use.
Always replace the whole set of batteries at one time; taking care not to mix old and new
ones, or batteries of different types. Clean the battery contacts and also those of the device
prior to battery installation. Make sure the batteries are installed correctly with regard to
polarity (+ and -). Remove batteries from equipment that is not to be used for an extended
period of time. Remove used batteries promptly. Never attempt to recharge primary
batteries as this may cause leakage, fire, or explosion. Never short-circuit batteries as this
may lead to high temperatures, leakage, or explosion. Never heat batteries in order to
revive them. Remember to switch off devices after use. Keep batteries out of the reach of
children, to avoid risk of ingestion, suffocation, or poisoning.
