Ersatzteilliste

Item # Part Name
1 Control Housing
2 Switch On/Off Lighted
3 Switch, Emergency Stop - Red
4 Switch, Print - Blue
5 Touch Screen Controller
6 Control Housing Overlay
7 Power Cord
8 Upper Casting
9 Base Casting
10 Rocker Arm
11 Main Swing Spindle
12 Stop Plate
13 Bearing Tapered Roller
14 Bearing Cup
15 Air Cylinder
16 Heat Platen 16 x 20
17 Heat Platen Cover
18 Lower Platen, 16 X20
19 Silicone Pad 16 X 20, Blue
20 Proximity Switch
21 Magnet, Slotted
22 Circuit Breaker, 20 Amp
23 Roller Bearing 6002
24 Grommet 5/16
25 Bearing, double shielded 6900
26 Nylok Nut 3/8-16
27 Adapter Plate
28 Quick Release Pin
29 Flange bushing 1"
30 C-clip
31 Main Spindle Washer
32 Hand Retractable Plunger
33 Needle Bearing 1/2"
34 Thermostat
35 Guide Tube
36 Pedestal Stand Assembly
37 Self Leveling Stem Caster
38 Foot Pedal Assembly
39 E/P Regulator
40 Drive Sprocket
41 Chain
42 Rotary Actuator
43 Mini Regulator
44 Print Valve
45 Swing Valve
46 Air Filter
47 IEC Inlet
48 Spanner Nut
49 Nord Lok Washer
50 Shock Absorber
51 Probe
52 Shock Stop Plate
53 Roll Pin 3/8"
Air Fusion™
®
Part #
1-2197
1-2087
1-2270
1-2271
1-2266
1-2198
2-1013-1
3-1341
3-1340
1-2308
2-1670
1-2284
1-2267
1-2268
1-2264
2-1002-3
1-2263
2-1029
1-2136
1-1211
1-1219
1-1331
1-2281
1-2285
1-2280
1-2301
3-1336
1-2215
1-2282
1-2286
1-2287
1-2288
1-2289
1-2076
1-2290
1-2291
1-2262
1-2305
1-2293
1-2306
1-2307
1-2296
1-2297
1-2298
1-2299
1-1215
1-1759
2-1006-95
2-1006-94
1-2300
1-1272-1
1-2302
1-1018-1
Qty.
1
1
1
2
1
1
1
1
1
1
1
1
2
2
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
2
1
1
4
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
18
