OBJ_BUCH-1398-004.book Page 13 Friday, July 5, 2013 11:42 AM
 Do not open the battery. Danger of short-circuiting.
Protect the battery against heat, e.g., against
continuous intense sunlight, fire, water, and
moisture. Danger of explosion.
 In case of damage and improper use of the battery, va-
pours may be emitted. Ventilate the area and seek
medical help in case of complaints. The vapours can irri-
tate the respiratory system.
 Use the battery only in conjunction with your Bosch
power tool. This measure alone protects the battery
against dangerous overload.
 Use only original Bosch batteries with the voltage list-
ed on the nameplate of your power tool. When using oth-
er batteries, e.g. imitations, reconditioned batteries or
other brands, there is danger of injury as well as property
damage through exploding batteries.
Product Description and
Specifications
Read all safety warnings and all instruc-
tions. Failure to follow the warnings and in-
structions may result in electric shock, fire
and/or serious injury.
While reading the operating instructions, unfold the graphics
page for the machine and leave it open.
Intended Use
The tool is intended for separating cuts in plastic, metal and
rubber while resting firmly against the material being sawn. It
is suitable for straight cuts with a bevel angle of up to 45°. Ob-
serve the saw-blade recommendations.
The light of this power tool is intended to illuminate the power
tool's direct area of working operation and is not suitable for
household room illumination.
Product Features
The numbering of the product features refers to the illustra-
tion of the machine on the graphics page.
1 Battery pack *
2 "PowerLight"
3 Lock-off button for On/Off switch
4 On/Off switch
5 Roller guide
6 Band-saw blade *
7 Direction-of-rotation arrow on housing
8 Lever for band-saw blade pre-tension
9 Auxiliary handle (insulated gripping surface)
10 Battery unlocking button *
11 Cover for band-saw blade
12 Screw
13 Saw blade guide
14 Handle (insulated gripping surface)
15 Button for charge-control indicator*
Bosch Power Tools
16 Battery charge-control indicator*
17 Roller for band-saw blade
18 Bolt hole
*Accessories shown or described are not part of the standard de-
livery scope of the product. A complete overview of accessories
can be found in our accessories program.
Technical Data
Band Saw
Article number
Rated voltage
No-load speed
Saw blade dimensions
Cutting depth, max.
Weight according to
EPTA-Procedure 01/2003
* dependent of the battery pack being used
Noise/Vibration Information
Measured sound values determined according to EN 60745.
Typically the A-weighted sound pressure level of the product
is 79 dB(A). Uncertainty K=3 dB.
The noise level when working can exceed 80 dB(A).
Wear hearing protection!
Vibration total values a (triax vector sum) and uncertainty K
h
determined according to EN 60745:
2
Cutting metal: a <2.5 m/s , K=1.5 m/s
h
The vibration emission level given in this information sheet
has been measured in accordance with a standardised test
given in EN 60745 and may be used to compare one tool with
another. It may be used for a preliminary assessment of expo-
sure.
The declared vibration emission level represents the main ap-
plications of the tool. However if the tool is used for different
applications, with different accessories or poorly maintained,
the vibration emission may differ. This may significantly in-
crease the exposure level over the total working period.
An estimation of the level of exposure to vibration should also
take into account the times when the tool is switched off or
when it is running but not actually doing the job. This may sig-
nificantly reduce the exposure level over the total working pe-
riod.
Identify additional safety measures to protect the operator
from the effects of vibration such as: maintain the tool and the
accessories, keep hands warm, organise work patterns.
Declaration of Conformity
We declare under our sole responsibility that the product de-
scribed under "Technical Data" is in conformity with the fol-
lowing standards or standardisation documents: EN 60745
according to the provisions of the directives 2009/125/EC
(Regulation 1194/2012), 2011/65/EU, 2004/108/EC,
2006/42/EC.
Technical file (2006/42/EC) at:
Robert Bosch GmbH, PT/ETM9,
D-70745 Leinfelden-Echterdingen
English | 13
GCB 18 V-LI
3 601 BA0 3..
V= 18
m/min 162
mm 733 x 12.7 x 0.5
mm 63.5
kg 3.6/3.8*
2
.
1 609 92A 0B0 | (5.7.13)
