BOX menu (Auto)
BOX Auto
Box Min 10%
Box Max 90%
<<BACK<<
Line 1: Select "Auto" for automatic operation of
the fan.
In "Auto" position, the fan will rotate faster
automatically if a measured value is too high.
That is, if TMP is higher than (TMP set + TMP
+/-).
The fan will rotate 10% faster every 5 seconds
until AutoMax value is reached. When the
measured values are normal, the fan will rotate
slower until the rest value AutoMin is reached.
Line 2 and 3: Adjustment of the minimum and
maximum fan speed in "Auto" position.
Line 4: <<BACK<<
BOX menu (Man)
BOX Man
Box Power 40%
<<BACK<<
Line 1: Select "Man" for manual operation of the
fan.
Line 2: Set the fan power manually between 0%
and 100%.
CO2 Min-Max menu
CO2 Min 519
CO2 Max 605
Reset Min/Max
<<BACK<<
RH Min-Max menu
RH Min 36%
RH Max 40%
Reset Min/Max
<<BACK<<
12

Min-Max values

Line 1: The measured minimum value of the
connected sensor.
Line 2: The measured maximum value of the
connected sensor.
Line 3: Place the arrow in front of Reset Min/Max
to reset the Min/Max values. The display returns
to the set-up menu after several seconds.
Line 4: << BACK <<
These measurements will not be saved during
power outages.
Connection and specifi cation of the
alarm contact
The Clima Control Plus is equipped with a
changeover contact for the alarm contact.
These contacts are ratet for 230V at 1A.
This contact is not suitable for high-power, but is
meant to switch an external relay.
When the Clima Control Plus is turned off , or
when all values are within limits, the NC contact
will be connected with the common (COMM)
connection. The NO contact is not connected
with anything in this state.
When the temperature rises above the alarm
temperature the contact will switch over, thus
connecting the NO contact with the common
(COMM) connection.
The NC contact is not connected with anything in
this state.
1. Unscrew the two screws holding the front
plate with the sockets, and lift the front plate
fron the rest of the enclosure.
2. Route the alarm cable through the right cable
gland.
3. Mount the wires from the alarm cable to the
right terminal blocks, by pushing in the white
levers with a small screwdriver, and inserting
the wire in the corresponding hole.
4. Fasten the cable gland
5. Replace the front plate and screws.
