10. Speaker: This speaker outputs audio signal from the record and stereo input.
11. Scratch Switch: Move this crossfader-style switch to mute or unmute the volume of the
speaker, headphones outputs, and line outs. This emulates the DJ technique of
"cutting" from one deck (turntable) to another.
Note: To adjust the angle of the Scratch switch, use a #5 screwdriver (screws have a 3.0
mm diameter) to remove the screws on either side of the switch, gently lift the circular
plate upward, turn it to the desired angle, and reinsert the screws securely.
Side Panels
1. Power Input: Use the included power adapter to connect this input to a power outlet, and
then power on the unit. Alternatively, insert 6 D-cell batteries (not included) into the battery
compartment on the underside of the turntable.
2. Power Switch: Use this switch to turn power on and off.
3. Line Outs (RCA): Connect these line-level outputs to the inputs of an external audio
device (mixer, PA system, powered speaker, etc.). Use the Audio knob to control the level
of the output signal.
4. Headphone Outputs (1/4", 1/8" / 6.35 mm, 3.5 mm): Connect stereo headphones to
either of these audio outputs.
Important: To avoid hearing damage, set the Audio knob to the Off position before
connecting headphones to either of these outputs.
5. Gain: Turn this knob to adjust the gain level of the stereo input. If the audio signal is too
quiet or too loud, use this knob to adjust the gain.
6. Stereo Input (1/8" / 3.5 mm): Connect this input to an additional audio device (computer,
smartphone, tablet, etc.). Use the Gain knob and your audio device's volume control to set
the level of the input signal. While using this input, make sure that your line outs are
connected to an external audio device and that the cables are not in contact with metal.
Note: The stereo input signal is sent to the line outs, not to your computer (through the
USB port).
7. USB Port: Use the included USB cable to connect this USB port to your computer. Please
note that the turntable cannot be powered through the USB connection. The signal from
the stereo input is not sent over this connection.
4 3 1 2
7 5 6
