List Of Parts - IKEA SLADDA Anleitung

2. BIKE PARTS & COMPONENTS
15
16
17
29
22
2
20
19
18 18
26
27
28
24
26
8
5
14 13
1 ICOMP knob connection and washer short (S:146902, W:146968)
3
2 ICOMP knob connection and washer long (S:147927, W:146968)
9
3 Handle bar (naked) (151271)
4 Grip (151278)
4
5 Handle bar stem with screws (151279)
7
6 Brake cable, complete (28":151333, 26":151340)
7 Left brake lever with bell (screw and adjuster included) (151280)
6
8 Right brake lever with/without bell (screw and adjuster included) (151281)
9 Bell (151282)
10 Tyre (28":151343, 26":151344)
1
11 Inner tube with valve (28":151316, 26":151331)
12 Brake disc with 6 screws (151346)
13 Brake pads, with spring and lock pin (152505)
14 Brake caliper with screws (152504)
15 Saddle (STD:151347, NA:152541)
16 Seat post (28":151348, 26:151354)
23
17 Seat post clamp with screw (151355)
18 Front and rear sprockets (28":151357, 26":151358)
21
19 Drive belt (151356)
10
20 Belt protection (28":151359, 26:151361)
11
21 Front wheel, complete. With rim tape. With/without inner-tube, tyre, brake-disc, reflectives
(28":151284, 26":151317)
25
22 Rear wheel, complete. With rim tape, nuts. With/without inner-tube, tyre, reflectives, sprocket
(28":152507, 26":151365)
12
23 Front mud guard, including screws (28:151366, 26:151368)
24 Kick stand (28:151370 26:151371)
25 Quick release front wheel, complete (152508)
26 Pedal with reflector (STD:151364, AU:152506)
27 Crank right (151362)
28 Crank left (151363)
29 Rear mud guard, including screws (28:151367, 26:151369)
5
