Switching the second display on/off:
The.seconds.appear.in.large.numbers.on.the.front.cover.
Switching.the.second.display.on:.Keep.the.[ ].button.pressed.for.approx..3.seconds.
>
Switching.the.second.display.off:.Press.any.button.
>
Setting the brightness:
The.brightness.level.adapts.automatically.to.the.surrounding.light.in.the."automatic.mode".(factory.setting).
The.level.of.brightness.can.also.be.set.manually.
Press.button.[ ].repeatedly..
>
The.settings.will.change.as.follows:
Maximum.brightness
. ■
Strong.brightness
. ■
Medium.brightness
. ■
Low.brightness
. ■
Automatic.mode.(minute.dots.in.the.corners.light.up.briefl .y)
. ■
3.3 Infrared remote control
Operation:
Settings.can.all.be.made.with.the.remote.control.
(included.in.delivery).
Hold.the.remote.control.underneath.the.QLOCKTWO.LARGE..
>
The.infrared.receiver.is.located.on.the.bottom.of.the.casing.
back..
Make.settings.with.the.remote.control.
>
The.function.of.the.buttons.corresponds.to.the.keys.on.the.
back.of.the.casing..
Replacing the battery:
The.remote.control.battery.is.to.be.replaced.when.the.
transmission.power.is.weak..
3.4 Setting the time of day with an app
The.time.of.day.can.be.transferred.easily.and.accurately.to.the.second.to.your.QLOCKTWO.LARGE.with.many.smartphones.by.
using.the.free.FLASHSETTER.app..More.information.available.at:.www.qlocktwo.com.>.LARGE.>.Functions
3.5 Power failure
The.time.of.day.continues.to.change.for.approx..24.hours.in.the.event.of.power.failure..The.current.time.of.day.will.be.shown.
automatically.when.the.power.supply.has.been.restored..The.settings.for.brightness.and.alarm.time.are.retained..A.visual.and.an.
acoustic.signal.will.follow.a.prolonged.power.failure.period.
14 6
3 V

4. Technical Data

Model:..
Dimensions.QLOCKTWO.LARGE.(H.x.W.x.D):..
Wall.mounting.bracket.dimensions.(H.x.W.x.D):..
Weight:.
Ambient.temperature:.
USB.power.supply.unit.port:.
USB.power.supply.unit.output:.
QLOCKTWO.CLASSIC.port:.
Remote.control,.battery:..
Precision:.
Technical.data.errors.and.modifi .cations.excepted.
No.liability.is.assumed.for.misprints.and.errors.
QLOCKTWO.LARGE
900.x.900.x.32.mm
710.x.710.x.38.mm
approx..25.kg
+15.°C.to.+30.°C
AC.100.V.−.240.V.~.50/60.Hz..2.A
DC.18.V.. ..2,33.A
DC.18.V.. ..1,2.A.
CR.2032,.3.V
±20.seconds/month
