Assembly Instructions HT4600 (Continued)
4. Programming
Set the desired call address for the device on the DIP-Switch following the SKS-BUS Address Table in
the appendix. Each call address is assigned to one call button in the door station. The call address
distribution is stored in the door station or in the door speaker 4503, 4508 or 4808.
Set the SKS-BUS call address on the intercom. Each
address is assigned to one call button at the door
station. The addresses are listed in the appendix. As a
rule, the SKS-BUS call address set in with "A1".
When replacing intercom units, set the DIP-Switch as
it is for the previously mounted intercom unit.
Press the front part down onto the rear part until the
clips snap into place. Make sure that no exposed
wires can touch the printed circuit board from behind.
