LevelOne NVR-0104 Handbuch Seite 4

4 NVR-0104 Quick Installation Guide
4
4. Attach the HDD to the SATA connector by sliding it towards the connector.
5. Secure the HDD with the screws provided. There are four for each HDD; two
for each side of the tray.
6
6. Install the top HDD by attaching it to the corresponding SATA cable. Make
sure the HDD is firmly attached.
7. Place the HDD onto the tray and secure the HDD with screws provided.
There are four for each HDD; two for each side of the tray.
8
8. Slide the side housing back to the unit.
9. Secure the housing with the screws.
5
7
9
