English

System Overview

Power LED
HDD1 LED
HDD2 LED
Channel LED
Remote Control
IR Receiver
USB Connector

HDD Installation

1
1. Remove the screws on the rear of the NVR.
2. Slide open the case.
3. Install the HDD by sliding it into the tray as shown in the photo.
Composite
Audio
Composite
Video
Power Button
2
NVR-0104 Quick Installation Guide
3
3
System Fan
USB Connector
Reset Button
HDMI Connector
Ethernet
Power Connector
