Jet 4224 Gebrauchsanleitung Seite 3

4. Machine specifications
4.1 Technical data
Swing over bed
Centre distance
Number of mechanical speeds
Spindle speed range L
Spindle speed range M
Spindle speed range H
Spindle nose M33x3,5 DIN 800
Headstock spindle taper
Spindle index lock
Spindle hole diameter
Tailstock spindle taper
Tailstock hole diameter
Tailstock ram travel
Centre above floor
Overall (LxWxH) 1730x660x1500mm
Footprint (LxW)
Net weight
Mains 230V ~1/N/PE 50Hz
Output power 2,2 kW (3 HP) S1
Reference current
Extension cord (H07RN-F): 3x1,5mm²
Installation fuse protection
4.2 Noise emission
Acoustic pressure level (EN 11202):
Idling
In operation
The specified values are emission
levels and are not necessarily to be
seen as safe operating levels.
As workplace conditions vary, this
information is intended to allow the
user to make a better estimation of the
hazards and risks involved only.
4.3 Content of delivery
Casting legs with levelling pads
350 mm tool rest
75mm face plate
Spur centre and tooling knockout bar
Live centre
Guard
Operating tools
Assembly kit
Operating manual
Spare parts list.
5. Transport and start up
5.1 Transport and installation
The machine is designed to operate in
closed rooms and must be placed
stable on firm and levelled ground.
The machine can be bolted down if
required.
For packing reasons the machine is
not completely assembled
610mm
5.2 Assembly
1065mm
If you notice transport damage while
3
unpacking, notify your supplier
0-910 rpm
immediately. Do not operate the
0-2000 rpm
machine!
0-3500 rpm
Dispose of the packing in an
environmentally friendly manner.
MT 2
Clean all rust protected surfaces with
24 x 15°
a mild solvent.
15,9mm
MT 2
9,5mm
115mm
1130mm
1620x610mm
360 kg
6.7 A
16A
Adjustable feet:
Thread adjustable feet (A, Fig 2) into
stand legs (B).
72,5 dB(A)
Adjust the feet so that the lathe rests
78,4 dB(A)
evenly on the floor, and tighten the
nuts (C).
Guard assembly:
Attach guard to the bracket by
inserting the rod and lifting up on the
plunger (A, Fig 3).
Fig 1
Fig 2
5
Fig 3
There are two detents that will hold
the guard in place.
One is for turning and the other is for
when you need the guard up and out
of the way.
Tighten the bushings (B) against the
bracket with two set screws (C).
5.3 Mains connection
Mains connection and any extension
cords used must comply with
applicable regulations.
The mains voltage must comply with
the information on the machine
licence plate.
The mains connection must have a
16 A surge-proof fuse.
Only use power cords marked
H07RN-F
Connections and repairs to the
electrical equipment may only be
carried out by qualified electricians.
5.4 Dust collection
Use a suitable dust collection and
filtration system to avoid a high dust
concentrations in the air.
5.5 Starting operation
You start the machine by pulling the
red ON/OFF button (F, Fig 4) and the
remote control ON/OFF button (J).
