• Also consider the safety instructions and the operating instructions of the other
devices connected to the unit.
• If you should not be clear about the correct connection or if questions should arise
that are not clarified in the course of the operating instructions, please contact our
technical support or another specialist.
Function description
The active box is controlled with a preamplifier signal via the XLR input.
The input signal is amplified and passed to the built-in speakers via the integrated
frequency switch.
The amplifier of the active box has a switching mechanism, i.e. it switches on auto-
matically if there is a signal at the input.
For protecting the amplifier, a protective circuit is built-in that switches off during
overheating or short-circuit at the output.
The volume of the active box is adjustable. The phase position can be switched.
The housing is equipped with carrying handles, protection corners, grating and a
flange for installing the box on a stand.
Start-up
In order to ensure an appropriate start-up, completely and care-
fully read these operating instructions with the safety instructions
before use!
18
Toute utilisation autre que celle décrite ci-dessus peut endommager le produit et
implique en plus des risques de courts-circuits, d'incendies etc.
Toute modification ou transformation de l´ensemble de l´appareil est interdite. Ne
pas ouvrir le boîtier !
Les consignes de sécurité doivent impérativement être respectées !
Désignation des constituants
voir volet rabattable
1
Interrupteur PHASE
2
Affichage POWER
3
Régulateur LEVEL
4
Prise LINE IN
5
Sélecteur de fonctions
6
Prise LINE OUT
7
Commutateur de sélection de secteur
8
Porte-fusible
9
Raccordement au réseau
Table des matières
Introduction ..............................................................................................................26
Utilisation conforme ..................................................................................................26
Désignation des constituants....................................................................................27
Table des matières ....................................................................................................27
Consignes de sécurité ..............................................................................................28
Description du fonctionnement ................................................................................29
Mise en service ........................................................................................................29
Installation ............................................................................................................30
Connexion au signal ..............................................................................................30
Raccordement au réseau ......................................................................................32
Commande ............................................................................................................32
Maniement ................................................................................................................34
Entretien ....................................................................................................................34
Elimination des éléments usés..................................................................................35
Dépannage ................................................................................................................35
Caractéristiques techniques ....................................................................................37
27
