Bauknecht KG 1173 A++ IO Bedienungsanleitung Seite 2

FAN (depending on the model)
The fan improves temperature distribution inside the
refrigerator compartment, allowing better preservation of
stored food
Important:
Do not obstruct the air intake area with food items.
The fan will run ONLY when the compressor is in
operation.
Fan with a button
To switch on or switch off the fan press the button (1a).
It is advisable to activate the fan when the ambient air
temperature is over 27 ÷ 28°C or if you perceive drops
of water on the glass shelves or in the severe humidity
conditions.
Fan switched on improves cooling conditions. To keep
preferable appliances setting, having the fan switched on,
there may be a need to adjust the thermostat.
If fridge is too cold the fan can be switched off.
Important:
Remember to turn off the fan when there is a lower
ambient air temperature.
Fan without a button
An electric system automatically turn on and turn off the
fan.
If the appliance has the fan it can be equipped with the
filter.
Remove it from the box (found in the crisper drawer
(item 6) and insert into the cover of fan (item 1b).
The replacement procedure is attached with the filter.
FRIDGE/FREEZER COMPARTMENT
CONTROLS
A. Thermostat knob
B. Light button
C. Thermostat setting indicator
D. Light bulb ((max power the
light bulb is given on the light
cover)
The thermostat adjusts temperature in both
compartments.
Thermostat set to 1/MIN: low cooling intensity
Thermostat set between 1/MIN and 7/MAX : cooling
intensity can be adjusted according to the preferences.
Thermostat set to 7/MAX: maximum refrigeration
intensity.
For the best food conservation 3-5/ MED position is
recommended.
Thermostat set to • : cooling and lighting off.
Thermostat set to ECO GREEN : ECO function active.
PRODUCT SHEET
FREEZING FRESH FOOD
Place the fresh food to be frozen into the bottom basket.
Avoid direct contact with already frozen food.
To freeze the quantity of food shown on the rating plate,
rotate the thermostat knob towards a slightly warmer
position just before fresh food insertion (for example, in
case of numbers, if chosen set value is 4 move it back to
3,5).
After 24 hours the food will be frozen. Move back the
thermostat knob to the previous position.
REPLACING THE LIGHT BULB
Before replacing the bulb, remove the power plug from
the mains socket.
To remove the light bulb turn anticlockwise as shown in
figure .
DEFROSTING THE FREEZER
COMPARTMENT
The freezer should be defrosted once
or twice a year or when excessive frost
is present (3 mm thickness).
The formation of frost is normal.
The amount and rate at which frost
accumulates depends on room conditions and how
often the door is open.
To defrost the unit, switch off the freezer compartment or
the whole appliance, depending on the model, and
remove all food products.
Leave the freezer door open to allow the frost to melt.
For appliances in figure only pull out the defrost water
drain and place a container under the drain.
When the operation is completed, put back the defrost
water drain.
Clean the inside of the freezer. Rinse and dry thoroughly.
Switch the freezer compartment, or the whole appliance,
back on and store the food inside.
DEFROSTING THE REFRIGERATOR
Refrigerator compartment defrosting is
completely automatic.
Droplets of water on the rear wall inside the
refrigerator compartment indicate that the
automatic defrost phase is in progress. The defrost
water is automatically run into a drain hole and
collected in a container, where it evaporates.
