A. Refrigerator Compartment
1. Filter in fan
2. Thermostat / light unit
3. Shelves / Shelf area
4. Cooler compartment (best for meat and fish)
5. Rating plate with commercial name
6. Fruits and vegetables crisper
7. Crisper divider
8. Reversibility kit
9. Egg tray
10. Separator
11. Door trays
B. Freezer Compartment
12. Storage zones for frozen food items ( basket or flap)
12a. "Eco green" basket (only in models with ECO
GREEN function)
13. Ice tray and/or cold accumulator
14. Bottom basket (freezing zone)
15. Door seals
16. The freezer door trays for pizza or other frozen food
with a short storage time (2** storage compartment).
Anti-bacterial protection (depending on the model):
- Antibacterial filter in the fan (1)
- Antibacterial additives in the Crisper (6)
- Door seals are made of material able to inhibit bacterial
growth (15).
Freezer using:
- The freezer compartment can be used without the
baskets / flap (with the exception of the bottom basket)
to increase storage and for large food. Place the food
directly on the racks.
After inserting food, ensure that the freezer
compartment door closes properly.
Notes:
- Depending on the model the number and type of
accessories may vary.
- In case of power failure the cold accumulator helps to
keep optimal storage temperature longer.
- All shelves and door trays are removable.
- The internal temperatures of the appliance depend on
the ambient temperature, frequency of opening the
doors, as well as location of the appliance. Temperature
setting must consider these factors.
- The appliance accessories are not suitable for washing in
dishwasher.
PRODUCT SHEET
ORGANIZING MAT (depending on the model)
The Organizing Mat is a mat
designed to better organize the
space on the shelf, and to
provide a soft-touch experience
when loading heavy items on the
shelf. Some slots could also be
used to host bottles (horizontally
positioned). In order to remove it (for cleaning purpose,
or to use it on top of another shelf), first remove the shelf
where it is currently placed. The mat is dishwashable.
NET SHELF (depending on the model)
The Net Shelf is the net which
can be used to store little items
directly under the glass shelf,
taking full advantage of this
space. Pull down the net shelf
(using the lip on the front) to
load/unload it.
The net is flexible: do not stress it by loading it with bulky
or heavy items. Maximum weight allowed: 2 kg.
To remove the net (for cleaning purpose, or to use it
under another shelf), you have to first remove the glass
shelf under which the net is currently placed. The net
shelf is dishwashable.
HOW TO START THE APPLIANCE
Fit the spacers (if supplied) on the
upper part of the condenser at the
rear of the appliance.
After plugging the appliance to the
mains, it starts the operation
automatically.
After starting the appliance, wait at least 4-6 hours before
placing food into the appliance .
Note:
• If food is placed in the refrigerator before the appliance
ECO GREEN FUNCTION
(depending on the model)
To select the function turn the ECO symbol on the knob
of the regulator.
GB PL CZ SK H
has cooled completely, it may deteriorate.
This function gives best food preservation
performance with the smallest energy
consumption possible (around 5-10% less in
comparison with the normal settings) if there is
lower amount of food to be preserved in the
appliance.
The best food preservation conditions when
ECO function is activated are in the ECO
compartments:
- 2 "eco green" shelves in the fridge (with green
frames)
- 1 "eco green" basket in freezer compartment
