Chapter 2: Using the SolarEdge Key
4
Long press SafeDC Enable. The screen displays SafeDC and
then N / Y?
5
Short press the right button (Confirm) to continue or the left
button (Esc) to abort;
If you confirmed, the screen displays a backward countdown
and then displays #OP: xx
(xx= number of power optimizers in the strings, between 0-30).
6
After 5 seconds, the string output voltage Vo is displayed
(xxx.x).
The SafeDC mode is now active and the voltage of each power
optimizer is 1V. The string voltage equals the number of power
optimizers (less than 30V). When connecting to inverters with
SMI, perform the Commissioning steps as described in the
SolarEdge SMI Installation Guide, available on the SolarEdge
website at
http://www.solaredge.com/files/pdfs/products/inverters/guid
es/se_installation_guide_safety_monitoring.pdf.
All the power optimizers must be logically paired to the SMI.
The power optimizers do not start producing power until they
are paired with an SMI.
