G20175; Installation; Operating The Unit; Suggestions - Trevidea G3Ferrari Neve G20175 Bedienungsanleitung

PARTS OF G20175
1. Motor
4. Removable bowl

INSTALLATION

CAUTION: ensure that the product is unplugged before performing any of the operations below.
- Remove each element of the package, before proceeding.
- Place the unit on a flat surface. Insert the removable bowl (4) inside the machine.
- Mount the motor (1) in its seat in the lid (2), pushing until lock.
- Install the mixing blade (3) in the drive shaft of the motor.
- Pour the mixture for ice cream in the container (4), then assembly
the lid with mounted blade, as shown in the figures:
- Place the lid with the arrow on "open" position
- Turn the lid clockwise bringing the arrow on "closed" position.
Pay attention to mount the lid correctly: there is an electric
contact that supplies the movement of the blade.
OPERATING
Check voltage to be sure that the voltage indicated on the rating label
agrees with your home voltage, then plug into the correct socket.
Set the desired function on the control panel (5).
Function ICE-CREAM . Activates both cooling and motor: suitable
to make ice-cream.
Function SLUSHIE
Function COOL . Activates only cooling, for more dense result.
Function MIX . Activates only the motor, for more smooth and less dense result.
At the end of the preset time or upon reaching the optimal hardness level, the machine emits 10 beeps to
signal the completion of the selected function
KEEP COOL FUNCTION
When the machine finishes a preparation, the machine runs the keep cool function. The appliance keeps the
ice-cream in temperature for up to one hour, in order to keep the taste and the texture of fresh ice cream. After
1 hour the machine makes 10 beeps and switches off.
WARNING: when the operation is finished, press the button
remains in stand-by.

SUGGESTIONS

- Since the ice expands when it is formed, to avoid overflow and waste of ice-cream, please make sure that
the ingredients do not exceed 60-65% of the removable bowl capacity (4).
- Once the process is finished, remove the ice cream from the bowl by using a scoop.
CAUTION: To avoid risk of electrical shock, you should always unplug the unit from the electrical wall
outlet before serving.

CLEANING -

WARNING: Always unplug the appliance from the electrical outlet before cleaning.
Do not immerse the appliance and power cable into the water.
Clean the exterior with a non-abrasive damp, avoid using detergents or abrasive or aggressive cleaning
agents. The cloth should not be too wet, as if water flows inside the cabinet, it can seriously damage the unit.
Wash the removable bowl (4) and the lid (2) as normal dishes, rinse and dry them thoroughly before
reinstalling.
2. Lid
. Activates both cooling and motor: suitable to make slushies, sorbets and granita.
3. Mixing blade
5. Control panel
to switch off the appliance, that otherwise
