Zeiss DIGISCOPING ADAPTER Kurzanleitung Seite 12

(1) (2) (3)
Increasing the distance to the eyepiece
A rear camera that is very prominent in relation to the smartphone housing can result
in the distance between the smartphone camera and the optical device being too
digiscoping adapter and your optical device so that you obtain a clear photo. The
Unscrew the star knob (1) and remove the washers (2), (3). Remove the adjustment arm
(4). Position the washers between the adjustment arm and the smartphone adapter (5).
in Fig. 11, Fig. 12 and Fig. 13. Then turn the star knob back into the thread of the
smartphone adapter.
Tips for the best results
• For photos without a black border: Zoom in until the black border disappears.
• For photos with a black border: Focus the smartphone on the black border and
then focus on the subject using the optical device.
• Stability: Use a stable tripod to keep the optical device steady.
• Shutter release: Activate the remote shutter release or timer on your
smartphone. Set the timer to 2-5 seconds to avoid shaking.
12
(4)
(5)
DESCRIPTION OF THE COMPONENTS
1. Star knob
2. Washer, 2 mm
3. Washer, 1 mm
4. Adjustment arm
5. Smartphone adapter
