3 Mounting

The bridge amplifier can be mounted with two M4 screws at the machine structure. For plug
connection please see chapter 4.2 electrical connections.
4

Function

4.1

Overview of the operating controls

5-Pol (Serie 713)
DABx_AD2T_BA_V1_0m.doc
01.04.09/rut
Inspection glass for LED
13/20
4-Pol female (Serie 712)
Reset button underneath
amplifier cover
