Owner's manual
IMPORTANT SAFETY INSTRUCTIONS
Read the manual and follow the instructions relating to safety tips, correct
and complete product assembly, setting into service, use and maintenance.
For your own safety, always heed the advice and warnings in these
instructions. Non-compliance with these operating instructions may expose
you to serious danger or death. Only use the product in the places and
conditions for which it is intended.
Stand-up Paddling is a dangerous sport. Use of this product exposes the
user to unexpected risks, dangers and hazards.
User should realize and understand these risks. The use of this product
implies the respect of the safety instructions described in the manual.
Do not exceed the maximum recommended number of persons.
Regardless of the number of persons on board, the total weight of persons
and equipment must never exceed the maximum recommended load.
Do not use this product if you are under the influence of alcohol, drugs or medications.
Life saving devices such as life jackets and buoys should be pre-inspected and used at all times.
Always paddle with an experienced partner when using this product.
Tell your sail routes and time schedule to your partner.
Check the weather forecast first to know the marine environment and weather conditions before starting. Bad
weather and marine environment is very dangerous.
Never use this product in conditions that are beyond your ability (such as, but not limited to, high surf, riptides,
currents or river rapids)
Use the product near the shore and beware of natural factors such as wind, tidewaters and tidal waves. BE AWARE
OF OFFSHORE WINDS AND CURRENTS.
Before every use, carefully inspect the product for signs of wear or leakage to ensure everything is in good condition.
Please do not use the SUP if you find any damage.
Do not surf in unfamiliar water areas.
Beware of potential harmful effects of liquids such as battery acid, oil and petrol. These liquids may damage the
product.
Inflate according to the rated pressure on the product or it will cause over inflation and/or an explosion.
Stay balanced. Uneven distribution of loads on the board may cause the board to overturn which could lead to
drowning.
Know how to operate this product. Check your local area for information and/or training as needed. Inform yourself
about local regulations and dangers related to surfing, boating and/or other water activities.
Technical Specifications
Item
65302 2.74m x 76cm x 15cm (9' x 30" x 6")
65303 3.05m x 84cm x 15cm (10' x 33" x 6")
65305; 65329 3.20m x 76cm x 15cm (10'6" x 30" x 6")
65306 3.81m x 76cm x 15cm (12'6" x 30" x 6")
65308 3.10m x 86cm x 15cm (10'2" x 34" x 6")
65310 3.40m x 89cm x 15cm (11'2" x 35" x 6")
65312; 65330 3.05m x 84cm x 15cm (10' x 33" x 6")
#65302
001
008
#65303
001
007
#65308
001
008
303021211239_21x28.5cm_20季SUP冲浪板说明书65302,65303,65305,65306,65308,65310,65312,65329,65330－英
Bestway Hydro-Force Freesoul Tech / Hydro-Force Kahawai / Hydro-Force Aqua Cruise Tech / Hydro-Force Oceana / Hydro-Force HuaKa'i Tech
Hydro-Force Fastblast Tech / Hydro-Force Aqua Journey / 65302 / 65303 / 65305 / 65329 / 65306 / 65308 / 65310 / 65312 / 65330
Warning
QUESTIONS? PROBLEMS?
SAVE THESE INSTRUCTIONS
Recommended Maximum Load
Inflated Size
Working pressure Capacity
1.03bar (15psi) 110kg (242lb)
1.03bar (15psi) 130kg (287lb)
1.03bar (15psi) 120kg (265lb)
1.03bar (15psi) 120kg (265lb)
1.03bar (15psi) 140kg (309lb)
1.03bar (15psi) 160kg (353lb)
1.03bar (15psi) 140kg (309lb)
002 003
009 010
004
002 003 005
008 009 010
002 003
009 010
#65329; #65330
TO THE STORE
MISSING PARTS?
For FAQ, Manuals, Videos Or
Spare Parts, Please Visit
bestwaycorp.com/support
#65305; #65306; #65312
001
#65310
Maximum Number
of persons
1 Adult
1 Adult
001
1 Adult
1 Adult
1 Adult
1 Adult
007
1 Adult
Part No. Description
001 Surf Board
002 High Pressure Hand Pump
003 Oar
004 Footrest Tube
005 Footrest Foam
006 Safety Rope
007 Seat
006 008 Wrench
009 Polyester 3-ply patch
010 Bag
011 Elastic Cord
012 Fin
Part No. Description
001 Surf Board
002 High Pressure Hand Pump
003 Oar
004 Footrest Tube
005 Footrest Foam
006 Safety Rope
007 Seat
008 Wrench
009 Polyester 3-ply patch
010 Bag
006
011 Elastic Cord
012 Fin
Installation
1. Spread out the surfboard on level ground.
2. Use your board at first time or after long period storage, check the air valve and tighten the valve with the provided
011 wrench first. (Fig. 1).
Attention: Don't adjust the air valve when the board is in use.
Warning: Don't rotate the wrench counterclockwise when inspect the inflation, or it will be danger.
3. Inflate the board by unscrewing the cap of the air valve (Fig.2 Pos.1). Ensure that the inner spring valve is not
depressed. If it is depressed (Fig.2 Pos. 2), press the spring valve and turn counter clockwise so the inner spring
valve is in the correct position (Fig.2 Pos. 3). Attached the hose to the inflate position on the high-pressure hand
pump. Inflate the board to 1.03bar (15psi). After inflation, screw the cap of air valve (Fig.2 Pos. 4)
NOTE: If over-inflation occurs, press the spring valve to release air to an acceptable level and securely fasten the
air valve.
NOTE: If the board is not in use and exposed under the sun, it may cause overexpansion and damage the board.
Check the pressure and deflate slightly until the correct pressure is obtained.
NOTE: Pressure gauge is for inflation purpose only, and the value of the pressure gauge is just for reference,
should not be used as a precision instrument.
006
011
1
001 002 003
008 009 010 011
006
002
009
010 011
002 003
008 009 010
SPARE PART SPARE PART SPARE PART
QTY
NO. (#65302) NO. (#65303) NO. (#65305)
1 P04483 P04484 P04485
1 P04481 P04481 P04481
1 P04491 P04492
1 / P5C499ASS16
1 / F6C211ASS16
1 P04490 P04490 P04497
1 / F6C336ASS18
1 F6H189ASS16 F6H189ASS16 F6H189ASS16
1 / /
1 P04024 P04024 F6669ASS18
1 / P03797 P03797
1 / / F3C197ASS18
SPARE PART SPARE PART SPARE PART
QTY
NO. (#65310) NO. (#65312) NO. (#65329)
1 P04488 P04489 P04485
1 P04481 P04481 P04481
P04492
1 / P04491
P5C499ASS16 /
1
F6C211ASS16 /
1
P04497 P04497 P04497
1
1 F6C336ASS18 /
1 F6H189ASS16 F6H189ASS16 F6H189ASS16
1 / /
1 P04025 F6669ASS18 F6669ASS18
1 P03798 P03797 P03797
1 F3C197ASS18 F3C197ASS18 F3C197ASS18
1 2
Fig. 1
006
012
008
012
004
005 006
011 012
SPARE PART SPARE PART
NO. (#65306) NO. (#65308)
P04486 P04487
P04481
P04481
P04491
/ /
/
/ /
/ / /
P04497 P04490
/ / /
F6H189ASS16 F6H189ASS16
/ / /
F6669ASS18 P04024
P03797 P04285
F3C197ASS18 /
SPARE PART
NO. (#65330)
P04489
P04481
P04491
/ /
/ /
P04497
/ /
F6H189ASS16
/ /
F6669ASS18
P03797
F3C197ASS18
3 4
Fig. 2
