If the device has been exposed to drastic temperature fluctuation (e.g. after transportation), do not switch it
on immediately. The arising condensation water might damage your device. Leave the device switched off
until it has reached room temperature.
This device falls under protection-class III. The device always has to be operated with an appropriate
transformer.
Always disconnect from the mains, when the device is not in use or before cleaning it.
Please note that damages caused by manual modifications on the device or unauthorized operation by
unqualified persons are not subject to warranty.
Keep away children and amateurs from the device!
There are no serviceable parts inside the device. Maintenance and service operations are only to be carried
out by authorized dealers.

3. OPERATING DETERMINATIONS

This device is a DMX-controller for controlling DMX-effects or spots in discotheques, on stages etc. This
product is allowed to be operated with a direct voltage of DC 10-12 V, 500 mA and was designed for indoor
use only.
Do not shake the device. Avoid brute force when installing or operating the device.
When choosing the installation-spot, please make sure that the device is not exposed to extreme heat,
moisture or dust. There should not be any cables lying around. You endanger your own and the safety of
others!
Operate the device only after having familiarized with its functions. Do not permit operation by persons not
qualified for operating the device. Most damages are the result of unprofessional operation!
Please use the original packaging if the device is to be transported.
Please consider that unauthorized modifications on the device are forbidden due to safety reasons!
Never remove the serial barcode from the device as this would make the guarantee void.
If this device will be operated in any way different to the one described in this manual, the product may suffer
damages and the guarantee becomes void. Furthermore, any other operation may lead to dangers like short-
circuit, burns, electric shock, etc.

4. DESCRIPTION

4.1 Features

Programmable DMX-controller
For all DMX-projectors with up to 6 control-channels • 4 different addresses can individually be controlled •
Further devices can be connected with the same address and will run synchronically • The number of
devices connected with each address is unlimited • 32 freely programmable chasers with up to 32 steps •
Joystick for manual mirror movement • Fixture selection via fixture keys • Program-Run for running all
programs • Program-Run also possible via random-function • 8 different shapes with different parameters •
Strobe-button for strobe-function • Segment-display and control-LEDs • Sound-control via ¼" mono jack-
socket or built-in microphone • Adjustable microphone-sensitivity • Blackout • 24 control-channels • For 19"-
rack mounting
