>> Compare voltage ranges, frequency ranges and
ports of all used products. These must match or be
w ithin the specified range.

4.2 Installing and Operating

The following types must be distinguished for correct
installation.
• 1 satellite position for one or more participants
• 2 satellite position for one or more participants
Depending on the used combination of devices, different
connections have to be installed. The most common
installation samples are listed in the following.

4.3 Installation samples

4.3.1 1 satellite, 1 participant

(Universal Single LNBs)
Fig. 1: 4.3.1 1 satellite, 1 participant (Universal Single LNBs)
Connect the Universal
Single LNBs to the input of
your satellite receiver.
29
