Parts
and electronics
1 Rest
2 Guide pin
3
Armchair foot
4
Seat
5 Cover
6 Guide rail
7
Handle
Before assembling the
armchair, please read
the assembly inst-
ructions and all warning and
safety instructions carefully!
A
Plug 220 V
B Power supply/charger
Connection cable
C
chair
Connection: chair
D
socket/battery
E Chair socket
Button
F1
battery indicator
Battery charge level
F2
indicator
G
Battery
Connection: battery/
H
chair socket
Connection cable
I battery/power supply/
chair electronics
J
Remote control
K1
K2 Backrest adjustment
L1 L2 Footrest adjustment
Stand-up assist
M1 M2
Mobility button
N
