TORO
Safety
Repairor replacedamaged parts,including decals.
1.
Check all safety devicesbefore each use.
Engine, blade and traction drive (self-propelled
2.
model) are designedto stop when the engine kill
control bar is released. Ensure the engine kill con-
trol bar and brake function properly before eachuse
of the mower.
Installing the Starter Rope
1. Pull the starter rope through the rope guide on the
handle. To make the rope easierto loop, squeeze
the control bar on the handle to release the blade
brake.
1
Figure 1
Rope Guide
Stopping
6. STOPPING—To stop the engine, release the con-
trol bar. Pull the wire off the spark plug if the
mower will be unattended
MODEL NO. 26630BC—4900001 & up
MODEL NO. 26635BC—4900001
2
2. Starter Rope
or not used.
& up
53 CM RECYCLER@
MOWER
Adjusting the Brake Cable
Whenever a new blade brake cable assembly is installed,
an adjustment is required.
1. Stop the engine. Pull the wire off the spark plug.
Remove the key from the switch on the electric start
model.
2. CHECK ADJUSTMENT—Move
toward the handle until the slack in the wire is
removed. The gap between the brake lever and the
handle must be
ment..
3. CHECK CABLE
the cable bracket. Insert
the brake lever
conduit until all slack
Then tighten the nut.
1
Self-Propelled models only
1. Brake lever
2. handle
FORM NO. 3316-824
ADDENDUM
the control
See step 3 for adjust-
CONDUIT—Loosen the nut on
object between
and handle. Pull down on the cable
is removed from the wire.
2
2,4-4,8mm
3
4
Figure 2
3. Nut
4. Cable conduit
EN
bar
