Rated voltage
Consumers' connection
Pulse output (floating)
Degree of protection
Class of protection
(dependent on correct assembly)
Permissible ambient temperature
Radio frequency
Dimensions
Problem
LED on radio socket does not light up
when transmitter is activated.
Consumer does not respond to
switching impulse.
20 - en
Technical data
230-240 V AC / 50 Hz
16 A / 230-240 V AC with cos
Umax 42 V; Imax 1 A DC
IP 20
II
-20 to +35°C
868.3 MHz
approx. 112 x 68 x 49 mm
What to do if...?
Insert new battery/batteries cor-
rectly.
Program transmitter.
Check fuse.
Reduce distance from radio socket.
Switch on consumer.
Check connection of the pulse con-
necting cable.
=1
Remedy
