2 - Feature
VRDM-CONTROL is a remote RDM control box (VRDM-Control) that enables it to perform all the various settings on
the projectors:
- Address a fixture in DMX
- Modify DMX mode
- Access to a Master Slave mode, to eliminate the need for a DMX controller
- Direct access to different DMX channels to adjust color or launch a color preset / CCT or macro already built
into the fixture.
- Check fixture version
- Perform updates on the fixture
- Modify dimmer curve
- Correct white balance
- View product hours
Package contents :
The packaging should contain the following:
- The box
- The user guide
- 1 USB-C cable
- 1 micro SD card
3 - Description
4
8
1
1
LCD display
Allows you to display the internal menu and view
information about each connected projector.
2
MODE key
It is used to start the controller and to switch it off
(press for 3 seconds).
It can also be used to navigate backwards through
the various menus.
3
Navigation keys
Allows you to move through the various menus, set
the values for each section and confirm your choices
with the ENTER key.
Page 8
VRDM-CONTROL -
5 6 7
Contest Architectural RDM updater controller
4
DMX input/output on 3-pin XLR
2
5
USB input (USB C)
When the USB-C cable is connected to a PC and the
VRDM-Control is switched on, the box is recognized
as a USB stick, and update files can be transferred.
The USB connection also recharges the VRDM-
Control's battery.
6
Micro SD port
3
Insert the
The micro SD card contains the projector firmware
update files.
7
DMX input/output on 5-pin XLR
8
Strap fastening notch
For attaching a wrist strap. This strap is not supplied.
micro SD card into the reader.
