● Read, understand, and follow all instructions before operating this device.
● Do not exceed rated capacity. Rated capacity is 136kg. (includes user, tools,
equipment and personal items).
● Sit down gently. Avoid shock loads caused by jumping or falling onto seat.
● Do not stand on seat.
● Beware of pinch and crush hazards when folding and unfolding.
● Keep out of the reach of children! This device is not appropriate for children's use.
● Use only on smooth, level surface capable of supporting the load.
PREPARATION
Before assembling your Folding Creeper, make sure all parts are present.
OPERATING INSTRUCTIONS
1. Unlock the spring loaded Lock Pin by pulling out until disengaged, at the same time
rotate the Head Frame and Middle Frame upward and back towards the Rear Frame
section until the Lock Pin can engage the Creeper Seat Locking Sleeve (Fig. 3). Ensure
Lock Pin is fully engaged.
Contents: See parts list
Figure 2- Attaching Creeper Casters
ASSEMBLY INSTRUCTIONS
1.Using the included open-end wrench,
attach two Casters to the threaded holes
in the Head Frame section. Use a 5 mm
hex key to fasten the remaining four
Casters to the Creeper Frame. Insert the
threaded Fasteners from the top and the
Casters from the bottom, then tighten with
hex key.
WARNING
Figure 3-Adjusting Creeper to seat
configuration
2.Flip Head Frame forward until
horizontal.
3.Unlock the spring loaded Lock Pin by
pulling out until disengaged,then
reverse steps1,2 to convert Creeper
Seat into Creeper.
Figure 4- Adjusting Seat to Creeper
configuration
