PF 230 milling machine technical data
Voltage:
Power rating:
Short-term operation
6 spindle speeds by shifting the V-belt:
280, 540, 780, 910, 1710, and 2500 rpm
Sleeve stroke
Vertical adjustment travel
Noise emission
Vibration
Dimensions
Weight
Only for operation in closed
rooms.
KT 230 compound-type table technical
data
Work area:
Adjustment travel in X direction: 170 mm
Adjustment travel in Y direction: 60 mm
Weight:
Dimensions of T-grooves:
Groove spacing:
Feed per rotation:
Feed per graduation line:

Assembly of the milling machine

Mounting on lathe PD 230/E

1. Mounting lathe on a firm base.
2. Attach the mounting block
screws (Do not tighten screws yet!)
2
3. Tighten screw (Fig. 6) and insert in pillar
3
4. Tighten screw to clamp the pillar.
4
5. Attach the milling table
using screws and square nuts
2
Mounting of milling machine on KT 230 compound-type
table
Safe and precise operation is only possible if the machine
is properly fastened to a stable work surface.
1. Attach compound-type table to work surface using 4
screws (M4, not included) (Fig. 8).
1
2. When working in conjunction with the PROXXON
PF 230 milling machine, insert pillar in flange and clamp
using screws .
2
The middle screw (between the two locking screws) is a
spreader screw. By tightening this screw, the opening can
be widened slightly, making it easier to insert the column.
Before clamping the column, do not forget to loosen this
screw again!
220 – 240 volts, 50/60 Hz
140 watt
10 min.
30 mm
200 mm
70 dB(A)
≤
2.5 m/s
2
≤
refer to Fig. 3
approx. 9 kg
270 mm x 80 mm
9.5 kg
refer to Fig. 4
25 mm
1.5 mm
0.05 mm
(Fig. 5) to the lathe
1
.
1
(Fig. 7) to the lathe support
3
.
1
Note:

Working with the milling device

Disconnect the mains plug before making any adjustments
on the milling machine!
The milling spindle on the PF 230 may be adjusted in
height in 2 ways (Fig. 9):
1. Using the fine tolerance feed
2. Using the drill lever

Height adjustment via fine tolerance feed

1. Loosen screw
2. Adjust to the desired height using the hand wheel
(1 rotation corresponds to 1 mm feed).
3. Screw
3

Feed via drill lever

1. Loosen screw
2. Loosen screw
Retighten screw
3. Adjust to the desired height using the drill lever
4. Retighten screw
The drill lever can be used for height adjustment as well as
for drilling. When drilling, do not tighten screw

Rotating milling spindle

using
The entire milling spindle may be rotated along 2 axes. To
3
rotate along the vertical axis, loosen screw
rotate entire pillar to the desired position. Then retighten
screw.
To rotate along the horizontal axis, loosen screw
and rotate milling spindle to the desired position. Adjust to
the desired degrees on scale
Important!
1
2
(Fig. 9).
3
must always be tightened again.
(Fig. 9).
4
and set scale to zero.
6 5
.
6
.
4
Note:
and retighten screw
2
1
.
2
.
4
(Fig. 6) and
4
(Fig. 10)
1
.
1
- 9 -
