Water pressure of 1-10 bars from your tap will enable your machine
to work more efficiently.(1 bar pressure means water flow of more
than 8 liters in 1 minute from a fully opened tap).
•
After connections are completed, check for the non-leakage of the
connection joints by turning on your tap completely.
•
Be sure that water inlet hoses are not folded, broken or crushed.
•
Mount the water inlet hoses to a 3"/4, geared water tap.

WATER DRAIN CONNECTION

•
Be sure that water inlet hoses are not folded, twisted, crushed or
elongated by stretching.
•
Water drain hose should be mounted at a height of minimum 60 cm,
maximum 100 cm from the ground.
•
The end of the water drain hose may directly be fitted to the dirty
water outlet hole or a special apparatus mounted on the outlet
bracket of the wash-stand.
•
Never attempt to extend the water drain hose by adding extra parts.
Cold water inlet (White filter valve)
Hot water inlet (Red filter valve)
