Scope of delivery

(1)
4.

Assembly

1st step: Fastening the front sight in the fan wheel cover
Insert the front sight into the cylinder cover over the line made by the chainsaw manufacturer.
The front sight is precisely adapted to each type of chainsaw and may have to be a little tight be
inserted. In this case, apply some lubricating oil and press in with force.
Notice:
Stihl chainsaws:
The side which is marked with „Top", must
point towards the cylinder cover.
(2)
(1) rear sight tip (front sight)
(2)
rear sight incl. magnet
(3)
cable ties for attachment
(4)
sheet metal magnet
(5)
mounting screws
(6) drill
Husqvarna chainsaws:
The tip will be plugged in like shown in the
picture below.
– 7 –
(3)
(4)
(5)
(6)
