RADICAL R-C10AD2 Installationsanleitung Für Masten Seite 7

[Hier eingeben]
COMPATIBILITY LIST
BRAND
AUDI
AUDI
AUDI
SEAT
SEAT
PLEASE NOTE:
- This head unit is not applicable to your car if the center console is 1 DIN structure.
- The installation of the Radical device should be carried out by an authorized installer. Specific
knowledge and tools are required to do the installation. Incorrect installation can cause damage to
the vehicle and the Radical device.
CAUTION:
- The target vehicle must factory configured with an OE radio or navigation systems. The Radical
device is not compatible with vehicles, which are equipped with a hybrid or electro drive.
- This device installation manual applies to vehicle platforms appearing in the compatibility list on
the previous page, and in a condition as offered by the respective vehicle manufacturer. Other
differing configurations and installations may result in complications and malfunctions.
THE KIT INCLUDES:
Nr. Artikel
1 Radical device
2 GPS antenna
3 WIFI Antenna
External BT MIC and Cable
4
3m
USB Cable 4P to 4P,USB-B
5
Female, Purple
USB Cable 4P to 6P,USB-B
6
Female, Green
7 AUX+RCA Cable 10PIN
8 SUBWOOFER Cable
9 Fuse 15A250V
Installation Tool Plastic
10
Handle
MODEL
A4 Sedan
A4 Avant
A4 Convertible
Exeo
Exeo ST
Menge
1
1
1
1
1
1
1
1
1
1
TYPE MODEL YEAR
B7 2004 > 2007
B7 2004 > 2007
B7 2006 > 2009
3R 2008 > 2013
3R 2009 > 2011
Power Cables Audi A3 A4
11 (Quadlock II, with 16PIN Can
Box Plug , length 300mm)
Power Cables Audi A3 A4
12 (ISO, with 16PIN Can Box
Plug , length 300mm)
13 ISO-DIN antenna adapter
14 CAN BUS for A3/A4
FM antenna adapter TWIN
15
FAKRA
16 FM antenna adapter ISO
17 Unit Discharge Key T=0.8mm
18 3M double Sticker
19 Quick start guide
1
1
1
1
1
1
4
1
1
