Lock program mode

If you want to protect your programs from undesired acces, you can lock the program mode.
Press and hold the Record-button.
Press the Rec Exit-button.
Release the Record-button.
The red LED above the Record-button is off.
Single Chase/Mix Chase
Über die Single Chase/Mix Chase-Taste können Sie den Chaser-Abspielmodus ändern. Im Single Chase-
Modus durchläuft der Controller einen Chaser.
Im Mix Chase-Modus werden alle ausgewählten Chaser gleichzeitig abgespielt.

Switch off individual DMX-channels

You can switch off an individual channel by pressing the Blind-button and the respective Flash-button.
In order to switch the channel on again, press the Home-button and the respective Flash-button.
Set all channels to maximum
Press the Full On-button and all channels will be set to their maximum value. As soon as you release the
button, the channels return to their original setting.
Blackout-Mode
Press the Blackout-button and all devices will be set to Blackout-mode.
MIDI In-mode
Press and hold the Record-button.
Press the Flash-button 1 in Preset A three times.
Release the Record-button.
The display shows "CH-1" and the Scene Setter is in MIDI In-mode.
Select the desired MIDI-channel by pressing the respective Flash-button in Preset A.
Press and hold the Record-button.
Press the Rec Exit-button.
The MIDI-channel was memorized and you are in the normal mode again.
MIDI Out-mode
Press and hold the Record-button.
Press the Flash-button 2 in Preset A three times.
Release the Record-button.
The display shows "CH-0" and the Scene Setter is in MIDI Out-mode.
Select the desired MIDI-channel by pressing the respective Flash-button in Preset A.
Press and hold the Record-button.
Press the Rec Exit-button.
The MIDI-channel was memorized and you are in the normal mode again.
22/23 70064545X87NXS_V_1_0.DOC
