Description
RAYSTAT-ECO-10 is an electronic controller with display, advanced alarm
facilities and the capability of switching large currents.
The RAYSTAT-ECO-10 is designed to control heating cable systems. Heat-
ing cable can be controlled either directly by the RAYSTAT-ECO-10 or via a
contactor.
Direct switching of heating cables is possible for heating loads up to 25 A.
For heating loads greater than 25 A indirect switching via a suitably rated
contactor controlled by a RAYSTAT-ECO-10 is necessary.
Installation and all wiring must be in accordance with applicable regulations.
The device must be installed in non hazardous areas only.
Tyco Thermal Controls offers other controls for use in hazardous areas.
Technical data
Supply voltage:
Main relay:
Heater operation on
sensor error:
Set point T range:
Accuracy:
Operatingtemperature: –30°C (–20°C, VDE approved) to +40°C ambient
User interface:
Power terminals:
Alarm terminals:
Sensor terminals:
Heater terminals:
Enclosure
Exposure Temperature: –40°C to +80°C
Ingress Protection:
Entries:
Size:
Weight:
Material:
Lid fixing:
Mounting:
6
230 Vac. +10%/–10%, 50/60 Hz (6V leakproof
maintenance-free non-rechargeable battery
incl. for programming without power supply)
max. 25 A, 250 Vac. Resistive
programmable: ON or OFF
0°C to + 30°C
±0,5 K at 5°C
4 x 7 segment digital display
4 push buttons
alarm relay, max. 2 A, 250 Vac. (Potential free)
2
3 x 0,75 mm to 4 mm
(3 + ) x 0,75 mm
(3 + ) x 0,75 mm
(2 + ) x 0,75 mm
IP 65
2 x M25, 1 x M20, 1 x M16
120 x 160 x 90 mm
approx. 800 gr.
polycarbonate
4 captive screws
on a wall or directly on the pipe using support
brackets, SB-100 / SB-101
2
2 2
to 2,5 mm
2 2
to 2,5 mm
2 2
to 4 mm
