Technical Data; Accessories Provided - Advanced Diagnostics Smart Pro Mini Gebrauchsanleitung

Gebrauchsanleitung - DE

2.2 TECHNICAL DATA

Technical
specifications:
Antenna
range frequencies:
Maximum power
radiated
Environmental
conditions:
Dimensions:
EN IEC 62368-1
compliant

2.3 ACCESSORIES PROVIDED

The following components are also included in the device package, packed separately:
OBD2 Cable
solo per mercato EMEA
adattatore PSA (ADC2023)
21
Supply voltage: 12V DC 1A con cavo OBD2
Supply voltage: 5V DC 500mA con cavo USB
Wi-Fi and BLE antenna: 2.4 GHz
Wi-Fi 802.11b/g/n
BLE (Bluetooth Low Energy)
The device operates at an ambient temperature between -20°C and 70°C
humidity: 0-95%RH, ambient pressure
Length: 172 mm
Width: 94 mm
Depth: 30 mm
Weight: 170 g
This product meets the requirements of the international standard EN IEC 62368-1
Keep out of the reach of children.
Copyright ADVANCED DIAGNOSTICS Ltd. 2025
• Operating frequency range: 2.412 - 2.484 GHz
• Maximun transmission power: +20 dBm(100mW)
• Operating frequency range: 2.400 - 2.484 GHz
• PMaximun transmission power: +9 dBm (8mW)
WARNING
D4A9388XA - SMART PRO MINI
