This product is subject to the provision of European Directive
2012/19/EC. The symbol showing a wheelie bin crossed through
indicates that the product requires separate refuse collection in the
European Union. This applies to the product and all accessories
marked with this symbol. Products marked as such may not be
discarded with normal domestic waste, but must be taken to a
collection point for recycling electrical and electronic devices

PRODUCT PARAMETERS

SPECIFICATIONS
Rated Voltage
Rated Current
Contact Resistance
Insulation Resistance
Service Life
Product Size
Installation hole dimensions
Level of Protection
Way To Install
INSTRUCTIONS
Connecting the 6-pin switch:
1. The public end (COM) is connected to the power input, and the normally open
(NO) or normally closed (NC) is connected to the load output.
2. For models with lights, the indicator pin should be connected to the live or
neutral line. Refer to the wiring diagram for details.
Gear shift:
2-pole switch: Move the rocker up or down to achieve circuit on and off.
3-pole switch: The middle is in the closed state, and the left and right movements
correspond to different functions (such as forward and reverse, high and low
speed).
KCD4
250VAC/ 125VAC
16A / 20A
<50mΩ~100mΩ
≥100MΩ
Over 10,000 times
31*25.2*31.8mm
27mm×21.5mm
IP20
Support screw fixation or
snap-in installation
