Safety at a Glance

By using this product, you signify that you have read, understand, and
accept the terms and conditions of this guideline and all instructions at
https://www.romo.tech/romo/downloads EXCEPT AS EXPRESSLY PROVIDED IN
AFTER-SALES SERVICE POLICIES AVAILABLE AT HTTPS://WWW.ROMO.TECH/
ROMO/DOWNLOADS, THE PRODUCT AND ALL MATERIALS AND CONTENT
AVAILABLE THROUGH THE PRODUCT ARE PROVIDED "AS IS" AND ON AN "AS
AVAILABLE" BASIS WITHOUT WARRANTY OR CONDITION OF ANY KIND. This
product is not intended for children.
Operating Environment
1. Indoor use only. DO NOT leave the product near heat sources.
2. DO NOT vacuum substances that may damage the product or cause accidents,
such as gravel, nails, gasoline or cigarettes .
1. Before each use, carefully check the area to be cleaned to ensure safe operation:
• Put away items like small valuables, fragile objects, cord-like items that could
tangle the robot, wet things that bubble up, and roll up draping fabrics.
• Clean sticky residues and standing water on the floor.
• Fence off robot-height objects, glass, and mirrors, or set no-go zones.
Safety Instructions
1. Make sure to be in compliance with local laws and regulations before use.
2. DO NOT disassemble or modify this product.
3. DO NOT place heavy objects on the product or use the robot to carry children
or pets. Keep the cleaning solution away from children and pets.
4. DO NOT approach, touch, or interfere with moving parts during robot
operation.
5. The mopped area may become slippery, make sure to walk with extra care on
such areas to avoid slipping.
6. Charge the robot using the provided power cord and base station. DO NOT
charge near flammable or combustible materials.
7. Make sure to power off the product and unplug the base station before
cleaning to prevent electric shock. Then, use a dry cloth to wipe and clean the
product.
8. DO NOT immerse or rinse the product. If the built-in battery comes into
contact with water, chemical decomposition may occur, potentially resulting
in the battery catching on fire, which may even lead to an explosion.
9. DO NOT dispose of the product in a regular waste disposal container. Strictly
follow your local regulations regarding the disposal and recycling of batteries.
1. If debris tangles in side brush, roller brush, or mop pad, remove and clean the
tangled part. DO NOT pull parts forcibly to prevent structural damage.
2. If parts are damaged, replace immediately. Only use genuine parts or officially
authorized parts.
3. Full functional testing is performed before shipment. Minimal water residue and
particulate matter in the product are normal.
4. For safe transportation, power off the product and use the original packaging. For
safe transportation, power off the product and use the original packaging.
5. Fogging inside the transparent housing may occur during operation. This is a
normal phenomenon and requires no action.
6. Dust particles or dark spots may be present inside the transparent housing. This is
a normal manufacturing characteristic and requires no action.
FAQ
Problems Possible Causes
Unable to power • Low battery. Charge the robot.
• The environment temperature is too low or high. The
on
device should be used between 0°C and 40°C.
Unable to charge • Base station has no power. Check power cord connection.
• Check and clean charging electrodes on both robot and
base station.
Low Charging To prolong battery cycle life, the robot automatically reduces
Speed charging speed when operating in low (<5°C) or high (>40°C)
temperature environments.
Failure to return to
• Objects blocking base station area. Remove immediately
the base station for for docking.
• Move the robot closer to base station.
charging
Unusual noise
• Check roller brush, side brush and wheels for tangled
debris.
during cleaning
Specification
General
Charging Temperature 5° to 40° C (41° to 104° F)
Operating Temperature 0° to 40° C (32° to 104° F)
Sweep & Mop Robot (Model: CR8E/CR8F)
Dimensions (Width ×
351 mm × 351.8 mm × 98 mm
Depth × Height)
Rated Voltage 14.4 V
Charge Voltage 20 V
Built-in Battery Capacity: 5000 mAh
Energy: 72 Wh
[1]
Charging Time 2 hours 30 minutes
Wi-Fi Protocol 802.11b/g/n, 802.11a/n/ac
Wi-Fi Operating Band 2.4000 GHz-2.4835 GHz: <20 dBm (CE)
and Transmitter Power 5.150 GHz-5.350 GHz: <23 dBm (CE)
(EIRP) [2] 5.470 GHz-5.725 GHz: <23 dBm (CE)
5.725 GHz-5.835 GHz: <14 dbm (CE)
Bluetooth Protocol Bluetooth 5.0
B l u e t o o t h O p e r a t i n g
Band and Transmitter 2.4000-2.4835 GHz: <10 dBm
Power (EIRP) [2]
Base Station (Model: CS8E/CS8F)
Dimensions (Width ×
453 mm × 425 mm × 440 mm
Depth × Height)
Rated Output 20 V
Bluetooth Protocol Bluetooth 5.1
Bluetooth Work
Frequency & Transmitter 2.4000-2.4835 GHz: <10 dBm
[2]
Power (EIRP)
Max Power [3] Charging Only: 55 W
Drying & Charging: 110 W
Dust Collection: 635 W
Mop Cleaning with Hot Water: 1100 W
Rated Input Current [3] 220 V-240 V, 50 Hz/60 Hz
For indoor use only
Read operator's manual
[1] Measured under 25° C (77° F) in laboratory conditions. The robot does not
enable the drying function, and uses the base station to charge from 0% to
100%. Performance may vary depending on environmental conditions, usage
patterns, and firmware versions.
[2] Operating frequency allowed varies among countries and regions. Please refer
to local laws and regulations for more information.
[3] Data varies by country and region.
