Digital ECOMETER · Operating and Installation Instruction

Installation

1. Unscrew the hub cap.
2. Remove the clasp locking ring and retaining key from the axle
nut.
3. Insert the retaining key of the new clasp locking ring with
integrated magnet into the groove between the axle stub and
the nut.
(Do not turn back the axle nut.)
Hook the clasp locking ring behind the edge of the axle nut.
Important!
The axle nut may come loose under extreme circumstances if the wedge is lost (danger of a
wheel coming off !).
04.001.21.24.0 V4 02.04.2014
Important!
It is essential to hook in the
safety lock on the clasp
locking ring!
