Digital ECOMETER · Operating and Installation Instruction

Setting the tyre rolling circumference

The unit is changed to setting mode by touching the reed contact in the hub cap with the magnet
(on the clasp locking ring) and at the same time bringing a metallic object close to the sensed area
on the outside of the display.
The display goes out if the setting procedure is interrupted for a long period. Pressing any contact
resumes the setting procedure from the point at which it was interrupted.
The display „9-U3248" appears for about 10 seconds as identifi cation of setting mode:
1. Pass the magnet over the reed contact. The fl ashing digit can be incremented by one every time
the sensed area on the outside of the display is activated (by a metallic object). After reaching 9,
the digit reverts to 0, etc.
2. Pass the magnet over the reed contact in the hub cap again. The next digit fl ashes. Set this one
as well by activating the sensed area on the outside of the display. Repeat this procedure until
the digits „3248" have been changed to the precise tyre rolling circumference that is required.
This confi rms the set tyre circumference.
04.001.21.24.0 V4 02.04.2014
