CONTROL LOCATIONS

FRONT VIEW
1. Handle
2. SKIP button
3. PROGRAM button
4. REPEAT button
5. MIC Volume control
6. ECHO control
7. Speaker (L)
8. Auto Voice control
ON/OFF button
9. CDG LED
10. REPEAT LED
11. Display
12. DISCO Light
13. STANDBY LED
14. button
REAR VIEW
27. iPhone/iPod holder
28. VIDEO OUT Jack
29. AUX OUT Jack (R)
30. AUX OUT Jack (L)
31. AUX IN Jack
32. DC IN Jack (9V)
E-2
SKIP button .15
STOP button .16
PLAY/PAUSE button .17
Master Volume
control .18
BALANCE control .19
Speaker (R) .20
DISCO Light
ON/OFF button .21
PLAY/PAUSE LED .22
PROGRAM LED .23
CD Door.24
MIC 1 Jack .25
MIC 2 Jack .26
Battery Door .33
