EXAMPLE CONFIGURATION CONTROL PRODUCT WITH SENSOR:
- PG04 Organic Response Sensor Node
- PG06 Casambi Sensor
stop
PF98
CONTROL (1)
CL
- PG04 Organic Response Sensor Node
1 Master sensor controls the DALI line
Other sensors are Slave
Examples:
PF98
MA
CONTROL
• Only 1 Master (MA) on same DALI line
• Daylight control will only be measured by the Master (MA) sensor node
• For other location of the Master (MA) sensor on the line, please contact iGuzzini
• The choise of "Personalities" on the app will be limited
PF98
CONTROL
SE
CONTROL CONTROL
SC
CONTROL (2)
CL
SL
CONTROL
4
SENSOR EDGE
SE
SENSOR CENTRAL
SC
CONTINUOS LINE
CL
stop
stop
SL
CONTROL
MASTER
MA
SLAVE
SL
